Accuride Drawer Slide DB3832EC-B Drawer Runners and Slides Featuring Soft Close, Hold In and Front Disconnect in black

Only %1 left
SKU
DB3832EC-B
More Information
Available Load Ratings 43Kg, 44Kg, 45Kg
Slide Lengths 350mm, 400mm, 450mm, 500mm, 550mm, 600mm, 650mm, 700mm
Travel Range 310mm, 406mm, 457mm, 508mm, 559mm, 610mm, 660mm, 711mm
Features Hold In, Soft Close (EC), Disconnect
Extension 100%
Finish Zinc Plate & Black Passivate (DB)
Height 45.7mm
Thickness 12.7mm
Fixings Included No
Sold as Pairs
Accuride Datasheets
Catalogues
main product photo
BASIC PRICE £24.36
All prices exclude VAT

Accuride Drawer Slide DB3832EC-B Drawer Runners and Slides Featuring Soft Close, Hold In and Front Disconnect in black - Features options are Hold In, Soft Close (EC), Disconnect, Travel Range options are 310mm, 406mm, 457mm, 508mm, 559mm, 610mm, 660mm, 711mm, Slide Lengths options are 350mm, 400mm, 450mm, 500mm, 550mm, 600mm, 650mm, 700mm, Available Load Ratings options are 43Kg, 44Kg, 45Kg, Extension options are 100%, Finish options are Zinc Plate & Black Passivate (DB), Height options are 45.7mm, Thickness options are 12.7mm, Sold in pairs

Metrol Springs
DB3832EC-B
/media/catalog/product/d/b/db3832ec-b.jpg
Add to Favourites
Note: adds the product to your favourites list in your account
  • Product code
    Product Description
    Stock Status
  • DB3832-0035EC-B
    Slide Length: 350mm, Load Rating: 43Kg, Sold as: Pairs
  • DB3832-0040EC-B
    Slide Length: 400mm, Load Rating: 44Kg, Sold as: Pairs
  • DB3832-0045EC-B
    Slide Length: 450mm, Load Rating: 45Kg, Sold as: Pairs
  • DB3832-0050EC-B
    Slide Length: 500mm, Load Rating: 45Kg, Sold as: Pairs
  • DB3832-0055EC-B
    Slide Length: 550mm, Load Rating: 45Kg, Sold as: Pairs
  • DB3832-0060EC-B
    Slide Length: 600mm, Load Rating: 45Kg, Sold as: Pairs
  • DB3832-0065EC-B
    Slide Length: 650mm, Load Rating: 44Kg, Sold as: Pairs
  • DB3832-0070EC-B
    Slide Length: 700mm, Load Rating: 43Kg, Sold as: Pairs
  • DB3832EC-B
    Sold as: Pairs
CAD Files
Accuride CAD files
  • 3832-0035EC-B STEP FILE
  • 3832-0040EC-B STEP FILE
  • 3832-0045EC-B STEP FILE
  • 3832-0050EC-B STEP FILE
  • 3832-0055EC-B STEP FILE
  • 3832-0060EC-B STEP FILE
  • 3832-0065EC-B STEP FILE
  • 3832-0070EC-B STEP FILE
