Accuride DB3832SC Drawer Runners and Slides with Self Close, Hold In and Front Disconnect Features in black

Only %1 left
SKU
DB3832SC
More Information
Available Load Ratings 48Kg, 49Kg, 50Kg
Slide Lengths 300mm, 350mm, 400mm, 450mm, 500mm, 550mm, 600mm, 650mm
Travel Range 286mm, 356mm, 406mm, 457mm, 508mm, 559mm, 610mm, 660mm
Features Self Close (SC), Hold In, Disconnect
Extension 100%
Finish Zinc Plate & Black Passivate (DB)
Height 45.7mm
Thickness 12.7mm
Brackets Optional Screw In
Fixings Included No
Sold as Pairs
Accuride Datasheets
Catalogues
BASIC PRICE £18.22
All prices exclude VAT

Accuride DB3832SC Drawer Runners and Slides with Self Close, Hold In and Front Disconnect Features in black - Features options are Self Close (SC), Hold In, Disconnect, Travel Range options are 286mm, 356mm, 406mm, 457mm, 508mm, 559mm, 610mm, 660mm, Slide Lengths options are 300mm, 350mm, 400mm, 450mm, 500mm, 550mm, 600mm, 650mm, Available Load Ratings options are 48Kg, 49Kg, 50Kg, Extension options are 100%, Finish options are Zinc Plate & Black Passivate (DB), Height options are 45.7mm, Thickness options are 12.7mm, Brackets options are Optional, Sold in pairs

Metrol Springs
DB3832SC
/media/catalog/product/d/b/db3832_6.jpg
  • Product code
    Product Description
    Stock Status
  • DB3832-0030SC
    Slide Length: 300mm, Load Rating: 48Kg, Sold as: Pairs
  • DB3832-0035SC
    Slide Length: 350mm, Load Rating: 49Kg, Sold as: Pairs
  • DB3832-0040SC
    Slide Length: 400mm, Load Rating: 50Kg, Sold as: Pairs
  • DB3832-0045SC
    Slide Length: 450mm, Load Rating: 50Kg, Sold as: Pairs
  • DB3832-0050SC
    Slide Length: 500mm, Load Rating: 50Kg, Sold as: Pairs
  • DB3832-0055SC
    Slide Length: 550mm, Load Rating: 50Kg, Sold as: Pairs
  • DB3832-0060SC
    Slide Length: 600mm, Load Rating: 50Kg, Sold as: Pairs
  • DB3832-0065SC
    Slide Length: 650mm, Load Rating: 49Kg, Sold as: Pairs
  • DB3832SC
    Sold as: Pairs
  • DB63335-2
    Sold as: Pairs
  • DB63340-2
    Sold as: Pairs
  • DB63345-2
    Sold as: Pairs
  • DB63350-2
    Sold as: Pairs
  • DB63355-2
    Sold as: Pairs
Accuride CAD files
  • 3832-0030SC STEP FILE
  • 3832-0035SC STEP FILE
  • 3832-0040SC STEP FILE
  • 3832-0045SC STEP FILE
  • 3832-0050SC STEP FILE
  • 3832-0055SC STEP FILE
  • 3832-0060SC STEP FILE
  • 3832-0065SC STEP FILE
