Accuride DB3832TR Drawer Runners and Slides with Touch Release, Hold In and Front Disconnect Features in black

Only %1 left
SKU
DB3832TR
More Information
Available Load Ratings 42Kg, 43Kg, 44Kg, 45Kg
Slide Lengths 300mm, 350mm, 400mm, 450mm, 500mm, 550mm, 600mm, 650mm, 700mm
Travel Range 305mm, 356mm, 406mm, 457mm, 508mm, 559mm, 610mm, 660mm, 711mm
Features Hold In, Touch Release (TR), Disconnect
Extension 100%
Finish Zinc Plate & Black Passivate (DB)
Height 45.7mm
Thickness 12.7mm
Fixings Included No
Sold as Pairs
Accuride Datasheets
Catalogues
BASIC PRICE £21.59
All prices exclude VAT

Accuride DB3832TR Drawer Runners and Slides with Touch Release, Hold In and Front Disconnect Features in black - Features options are Hold In, Touch Release (TR), Disconnect, Travel Range options are 305mm, 356mm, 406mm, 457mm, 508mm, 559mm, 610mm, 660mm, 711mm, Slide Lengths options are 300mm, 350mm, 400mm, 450mm, 500mm, 550mm, 600mm, 650mm, 700mm, Available Load Ratings options are 42Kg, 43Kg, 44Kg, 45Kg, Extension options are 100%, Finish options are Zinc Plate & Black Passivate (DB), Height options are 45.7mm, Thickness options are 12.7mm, Sold in pairs

Metrol Springs
DB3832TR
/media/catalog/product/d/b/db3232tr.jpg
  • Product code
    Product Description
    Stock Status
  • DB3832-0030TR
    Slide Length: 300mm, Load Rating: 42Kg, Sold as: Pairs
  • DB3832-0035TR
    Slide Length: 350mm, Load Rating: 43Kg, Sold as: Pairs
  • DB3832-0040TR
    Slide Length: 400mm, Load Rating: 44Kg, Sold as: Pairs
  • DB3832-0045TR
    Slide Length: 450mm, Load Rating: 45Kg, Sold as: Pairs
  • DB3832-0050TR
    Slide Length: 500mm, Load Rating: 45Kg, Sold as: Pairs
  • DB3832-0055TR
    Slide Length: 550mm, Load Rating: 45Kg, Sold as: Pairs
  • DB3832-0060TR
    Slide Length: 600mm, Load Rating: 45Kg, Sold as: Pairs
  • DB3832-0065TR
    Slide Length: 650mm, Load Rating: 44Kg, Sold as: Pairs
  • DB3832-0070TR
    Slide Length: 700mm, Load Rating: 43Kg, Sold as: Pairs
  • DB3832TR
    Sold as: Pairs
Accuride CAD files
  • 3832-0030TR STEP FILE
  • 3832-0035TR STEP FILE
  • 3832-0040TR STEP FILE
  • 3832-0045TR STEP FILE
  • 3832-0050TR STEP FILE
  • 3832-0055TR STEP FILE
  • 3832-0060TR STEP FILE
  • 3832-0065TR STEP FILE
  • 3832-0070TR STEP FILE
