Accuride DH3832 Corrosion Resistant, Telescopic Runners and Slides with Hold In and Front Disconnect Feaures

Only %1 left
SKU
DH3832
More Information
Available Load Ratings 45Kg, 46Kg, 47Kg, 48Kg, 49Kg, 50Kg
Slide Lengths 148mm, 199mm, 250mm, 300mm, 350mm, 400mm, 450mm, 500mm, 550mm, 600mm, 650mm, 700mm
Travel Range 138mm, 203mm, 254mm, 305mm, 356mm, 406mm, 457mm, 508mm, 559mm, 610mm, 660mm, 711mm
Features Hold In, Disconnect, Corrosion Resistance
Extension 100%
Finish Corrosion Resistant Plating (DH)
Height 45.7mm
Thickness 12.7mm
Fixings Included No
Sold as Pairs
Accuride Datasheets
Catalogues
BASIC PRICE £26.87
All prices exclude VAT

Accuride DH3832 Corrosion Resistant, Telescopic Runners and Slides with Hold In and Front Disconnect Feaures - Features options are Hold In, Disconnect, Corrosion Resistance, Travel Range options are 138mm, 203mm, 254mm, 305mm, 356mm, 406mm, 457mm, 508mm, 559mm, 610mm, 660mm, 711mm, Slide Lengths options are 148mm, 199mm, 250mm, 300mm, 350mm, 400mm, 450mm, 500mm, 550mm, 600mm, 650mm, 700mm, Available Load Ratings options are 45Kg, 46Kg, 47Kg, 48Kg, 49Kg, 50Kg, Extension options are 100%, Finish options are Corrosion Resistant Plating (DH), Height options are 45.7mm, Thickness options are 12.7mm, Sold in pairs

Metrol Springs
DH3832
/media/catalog/product/d/h/dh3832_2_-resized.jpg
  • Product code
    Product Description
    Stock Status
  • DH3832-0015
    Slide Length: 148mm, Load Rating: 45Kg, Sold as: Pairs
  • DH3832-0020
    Slide Length: 199mm, Load Rating: 46Kg, Sold as: Pairs
  • DH3832-0025
    Slide Length: 250mm, Load Rating: 47Kg, Sold as: Pairs
  • DH3832-0030
    Slide Length: 300mm, Load Rating: 48Kg, Sold as: Pairs
  • DH3832-0035
    Slide Length: 350mm, Load Rating: 49Kg, Sold as: Pairs
  • DH3832-0040
    Slide Length: 400mm, Load Rating: 50Kg, Sold as: Pairs
  • DH3832-0045
    Slide Length: 450mm, Load Rating: 50Kg, Sold as: Pairs
  • DH3832-0050
    Slide Length: 500mm, Load Rating: 50Kg, Sold as: Pairs
  • DH3832-0055
    Slide Length: 550mm, Load Rating: 50Kg, Sold as: Pairs
  • DH3832-0060
    Slide Length: 600mm, Load Rating: 50Kg, Sold as: Pairs
  • DH3832-0065
    Slide Length: 650mm, Load Rating: 49Kg, Sold as: Pairs
  • DH3832-0070
    Slide Length: 700mm, Load Rating: 48Kg, Sold as: Pairs
  • DH3832
    Sold as: Pairs
Accuride CAD files
  • DH3832-0015 STEP FILE
  • DH3832-0020 STEP FILE
  • DH3832-0025 STEP FILE
  • DH3832-0030 STEP FILE
  • DH3832-0035 STEP FILE
  • DH3832-0040 STEP FILE
  • DH3832-0045 STEP FILE
  • DH3832-0050 STEP FILE
  • DH3832-0055 STEP FILE
  • DH3832-0060 STEP FILE
  • DH3832-0065 STEP FILE
  • DH3832-0070 STEP FILE
