Accuride DS2728 Stainless Steel 304, Telescopic Drawer Runners and Slides with Hold In Feature

Only %1 left
SKU
DS2728
More Information
Available Load Ratings 15Kg, 18Kg, 20Kg
Slide Lengths 250mm, 300mm, 350mm, 400mm, 450mm, 490mm
Travel Range 170mm, 208mm, 245mm, 283mm, 320mm, 347mm
Features Hold In, Corrosion Resistance
Extension 75%
Finish Stainless Steel 304 (DS)
Height 26.5mm
Thickness 9.5mm
Brackets Optional Screw In
Fixings Included No
Sold as Pairs
Catalogues
Accuride Datasheets
BASIC PRICE £27.39
All prices exclude VAT

Accuride DS2728 Stainless Steel, Telescopic Drawer Runners and Slides with Hold In Feature - Features options are Hold In, Corrosion Resistance, Travel Range options are 170mm, 208mm, 245mm, 283mm, 320mm, 347mm, Slide Lengths options are 250mm, 300mm, 350mm, 400mm, 450mm, 490mm, Available Load Ratings options are 15Kg, 18Kg, 20Kg, Extension options are 75%, Finish options are High Grade Stainless Steel (DS), Height options are 26.5mm, Thickness options are 9.5mm, Sold in pairs

Metrol Springs
DS2728
/media/catalog/product/d/s/ds2728_2_-resized.jpg
  • Product code
    Product Description
    Stock Status
  • DS2728-0025
    Slide Length: 250mm, Load Rating: 15Kg, Sold as: Pairs
  • DS2728-0030
    Slide Length: 300mm, Load Rating: 18Kg, Sold as: Pairs
  • DS2728-0035
    Slide Length: 350mm, Load Rating: 20Kg, Sold as: Pairs
  • DS2728-0040
    Slide Length: 400mm, Load Rating: 20Kg, Sold as: Pairs
  • DS2728-0045
    Slide Length: 450mm, Load Rating: 20Kg, Sold as: Pairs
  • DS2728-0050
    Slide Length: 490mm, Load Rating: 18Kg, Sold as: Pairs
  • DS2728
    Sold as: Pairs
  • DS63610
    Sold as: Pairs
Accuride CAD files
  • DS2728-0025 STEP FILE
  • DS2728-0030 STEP FILE
  • DS2728-0035 STEP FILE
  • DS2728-0040 STEP FILE
  • DS2728-0045 STEP FILE
  • DS2728-0050 STEP FILE
  • DS63610 STEP FILE
