Accuride DZ2601 Drawer Runners and Slides with Low Profile and Hold In Feature

Only %1 left
SKU
DZ2601
More Information
Available Load Ratings 12Kg, 16Kg, 25Kg, 30Kg, 32Kg, 35Kg, 45Kg
Slide Lengths 150mm, 200mm, 250mm, 300mm, 350mm, 400mm, 450mm, 500mm, 550mm
Travel Range 147.5mm, 209mm, 259mm, 308mm, 357mm, 406mm, 456mm, 505mm, 554mm
Features Hold In
Extension 100%
Finish Zinc Plate & Blue Passivate (DZ)
Height 26.3mm
Thickness 12.7mm
Fixings Included No
Sold as Pairs
Catalogues
Accuride Datasheets
BASIC PRICE £23.17
All prices exclude VAT

Accuride DZ2601 Drawer Runners and Slides with Low Profile and Hold In Feature - Features options are Hold In, Travel Range options are 147.5mm, 209mm, 259mm, 308mm, 357mm, 406mm, 456mm, 505mm, 554mm, Slide Lengths options are 150mm, 200mm, 250mm, 300mm, 350mm, 400mm, 450mm, 500mm, 550mm, Available Load Ratings options are 12Kg, 16Kg, 25Kg, 30Kg, 32Kg, 35Kg, 45Kg, Extension options are 100%, Finish options are Zinc Plate & Blue Passivate (DZ), Height options are 26.3mm, Thickness options are 12.7mm, Sold in pairs

Metrol Springs
DZ2601
/media/catalog/product/2/6/2601_2_-resized.jpg
  • Product code
    Product Description
    Stock Status
  • DZ2601-0015
    Slide Length: 150mm, Load Rating: 12Kg, Sold as: Pairs
  • DZ2601-0020
    Slide Length: 200mm, Load Rating: 16Kg, Sold as: Pairs
  • DZ2601-0025
    Slide Length: 250mm, Load Rating: 25Kg, Sold as: Pairs
  • DZ2601-0030
    Slide Length: 300mm, Load Rating: 32Kg, Sold as: Pairs
  • DZ2601-0035
    Slide Length: 350mm, Load Rating: 35Kg, Sold as: Pairs
  • DZ2601-0040
    Slide Length: 400mm, Load Rating: 45Kg, Sold as: Pairs
  • DZ2601-0045
    Slide Length: 450mm, Load Rating: 45Kg, Sold as: Pairs
  • DZ2601-0050
    Slide Length: 500mm, Load Rating: 35Kg, Sold as: Pairs
  • DZ2601-0055
    Slide Length: 550mm, Load Rating: 30Kg, Sold as: Pairs
  • DZ2601
    Sold as: Pairs
Accuride CAD files
  • DZ2601-0015 STEP FILE
  • DZ2601-0020 STEP FILE
  • DZ2601-0025 STEP FILE
  • DZ2601-0030 STEP FILE
  • DZ2601-0035 STEP FILE
  • DZ2601-0040 STEP FILE
  • DZ2601-0045 STEP FILE
  • DZ2601-0050 STEP FILE
  • DZ2601-0055 STEP FILE
