Accuride DZ3320-50 Drawer Runners and Slides with Hold In, Front Disconnect and Bayonet Mounting

Only %1 left
SKU
DZ3320-50
More Information
Available Load Ratings 55Kg, 57Kg, 58Kg, 59Kg, 60Kg
Slide Lengths 300mm, 350mm, 400mm, 450mm, 500mm, 550mm, 600mm, 650mm, 700mm
Travel Range 325mm, 374mm, 424mm, 473mm, 522mm, 571mm, 620mm, 670mm, 731mm
Features Hold In, Disconnect
Extension 100% +
Finish Zinc Plate & Blue Passivate (DZ)
Height 50.8mm
Thickness 12.7mm
Brackets Optional Bayonet Mounting
Fixings Included No
Sold as Pairs
Catalogues
Accuride Datasheets
main product photo
BASIC PRICE £26.50
All prices exclude VAT

Accuride DZ3320-50 Drawer Runners and Slides with Hold In and Front Disconnect Features - Features options are Hold In, Disconnect, Travel Range options are 325mm, 374mm, 424mm, 473mm, 522mm, 571mm, 620mm, 670mm, 731mm, Slide Lengths options are 300mm, 350mm, 400mm, 450mm, 500mm, 550mm, 600mm, 650mm, 700mm, Available Load Ratings options are 55Kg, 57Kg, 58Kg, 59Kg, 60Kg, Extension options are 100% +, Finish options are Zinc Plate & Blue Passivate (DZ), Height options are 50.8mm, Thickness options are 12.7mm, Brackets options are Optional, Sold in pairs

Metrol Springs
DZ3320-50
/media/catalog/product/3/3/3320-50_2_-resized.jpg
Add to Favourites
Note: adds the product to your favourites list in your account
  • Product code
    Product Description
    Stock Status
  • DZ3320-5030
    Slide Length: 300mm, Load Rating: 55Kg, Sold as: Pairs
  • DZ3320-5035
    Slide Length: 350mm, Load Rating: 57Kg, Sold as: Pairs
  • DZ3320-5040
    Slide Length: 400mm, Load Rating: 58Kg, Sold as: Pairs
  • DZ3320-5045
    Slide Length: 450mm, Load Rating: 59Kg, Sold as: Pairs
  • DZ3320-5050
    Slide Length: 500mm, Load Rating: 60Kg, Sold as: Pairs
  • DZ3320-5055
    Slide Length: 550mm, Load Rating: 60Kg, Sold as: Pairs
  • DZ3320-5060
    Slide Length: 600mm, Load Rating: 59Kg, Sold as: Pairs
  • DZ3320-5065
    Slide Length: 650mm, Load Rating: 57Kg, Sold as: Pairs
  • DZ3320-5070
    Slide Length: 700mm, Load Rating: 55Kg, Sold as: Pairs
  • DZ3320-50
    Sold as: Pairs
  • DZLADD-0060-2
    Sold as: Kits (Front and Rear Strip)
CAD Files
Accuride CAD files
  • DZ3320-5030 STEP FILE
  • DZ3320-5035 STEP FILE
  • DZ3320-5040 STEP FILE
  • DZ3320-5045 STEP FILE
  • DZ3320-5050 STEP FILE
  • DZ3320-5055 STEP FILE
  • DZ3320-5060 STEP FILE
  • DZ3320-5065 STEP FILE
  • DZ3320-5070 STEP FILE
