Accuride DZ4180 Drawer Runners and Slides supporting up to 980Kg

Trustpilot
Be the first to review this product
CODE
DZ4180
BASIC PRICE: £392.54
- +
Metrol Springs
DZ4180
/media/catalog/product/4/1/4180.jpg
Add to Favourites
Note: adds the product to your favourites list in your account
main product photo
  • Product code
    Product Description
    Stock Status
  • DZ4180-080-035-0050U
    Slide Length: 500mm, Sold as: Individually
  • DZ4180-080-035-0055U
    Slide Length: 550mm, Sold as: Individually
  • DZ4180-080-035-0060U
    Slide Length: 600mm, Sold as: Individually
  • DZ4180-080-035-0065U
    Slide Length: 650mm, Sold as: Individually
  • DZ4180-080-035-0070U
    Slide Length: 700mm, Sold as: Individually
  • DZ4180-080-035-0075U
    Slide Length: 750mm, Sold as: Individually
  • DZ4180-080-035-0080U
    Slide Length: 800mm, Sold as: Individually
  • DZ4180-080-035-0085U
    Slide Length: 850mm, Sold as: Individually
  • DZ4180-080-035-0090U
    Slide Length: 900mm, Sold as: Individually
  • DZ4180-080-035-0095U
    Slide Length: 950mm, Sold as: Individually
  • DZ4180-080-035-0100U
    Slide Length: 1000mm, Sold as: Individually
  • DZ4180-080-035-0105U
    Slide Length: 1050mm, Sold as: Individually
  • DZ4180-080-035-0110U
    Slide Length: 1100mm, Sold as: Individually
  • DZ4180-080-035-0115U
    Slide Length: 1150mm, Sold as: Individually
  • DZ4180-080-035-0120U
    Slide Length: 1200mm, Sold as: Individually
  • DZ4180-080-035-0125U
    Slide Length: 1250mm, Sold as: Individually
  • DZ4180-080-035-0130U
    Slide Length: 1300mm, Sold as: Individually
  • DZ4180-080-035-0135U
    Slide Length: 1350mm, Sold as: Individually
  • DZ4180-080-035-0140U
    Slide Length: 1400mm, Sold as: Individually
  • DZ4180-080-035-0145U
    Slide Length: 1450mm, Sold as: Individually
  • DZ4180-080-035-0150U
    Slide Length: 1500mm, Sold as: Individually
  • DZ4180-080-035-0155U
    Slide Length: 1550mm, Sold as: Individually
  • DZ4180-080-035-0160U
    Slide Length: 1600mm, Sold as: Individually
  • DZ4180-080-035-0165U
    Slide Length: 1650mm, Sold as: Individually
  • DZ4180-080-035-0170U
    Slide Length: 1700mm, Sold as: Individually
  • DZ4180-080-035-0175U
    Slide Length: 1750mm, Sold as: Individually
  • DZ4180-080-035-0180U
    Slide Length: 1800mm, Sold as: Individually
  • DZ4180-080-035-0185U
    Slide Length: 1850mm, Sold as: Individually
  • DZ4180-080-035-0190U
    Slide Length: 1900mm, Sold as: Individually
  • DZ4180-080-035-0195U
    Slide Length: 1950mm, Sold as: Individually
  • DZ4180-080-035-0200U
    Slide Length: 2000mm, Sold as: Individually
MORE INFORMATION
More Information
Available Load Ratings 410Kg, 434Kg, 458Kg, 482Kg, 506Kg, 530Kg, 554Kg, 578Kg, 602Kg, 626Kg, 650Kg, 674Kg, 698Kg, 722Kg, 746Kg, 770Kg, 794Kg, 818Kg, 842Kg, 866Kg, 890Kg, 905Kg, 920Kg, 930Kg, 940Kg, 950Kg, 955Kg, 960Kg, 970Kg, 980Kg
Slide Lengths 500mm, 550mm, 600mm, 650mm, 700mm, 750mm, 800mm, 850mm, 900mm, 950mm, 1000mm, 1050mm, 1100mm, 1150mm, 1200mm, 1250mm, 1300mm, 1350mm, 1400mm, 1450mm, 1500mm, 1550mm, 1600mm, 1650mm, 1700mm, 1750mm, 1800mm, 1850mm, 1900mm, 1950mm, 2000mm
Travel Range 500mm, 550mm, 600mm, 650mm, 700mm, 750mm, 800mm, 850mm, 900mm, 950mm, 1000mm, 1050mm, 1100mm, 1150mm, 1200mm, 1250mm, 1300mm, 1350mm, 1400mm, 1450mm, 1500mm, 1550mm, 1600mm, 1650mm, 1700mm, 1750mm, 1800mm, 1850mm, 1900mm, 1950mm, 2000mm
Extension 100%
Finish Zinc Plate & Blue Passivate (DZ)
Height 80mm
Thickness 35mm
Fixings Included No
Sold as Individually
REVIEWS
Write Your Own Review
Only registered users can write reviews. Please Sign in or create an account
DOCUMENTS
No documents available, please contact us.
CAD FILES
Accuride CAD files
  • DZ4180-080-035-0050U STEP FILE
  • DZ4180-080-035-0055U STEP FILE
  • DZ4180-080-035-0060U STEP FILE
  • DZ4180-080-035-0065U STEP FILE
  • DZ4180-080-035-0070U STEP FILE
  • DZ4180-080-035-0075U STEP FILE
  • DZ4180-080-035-0080U STEP FILE
  • DZ4180-080-035-0085U STEP FILE
  • DZ4180-080-035-0090U STEP FILE
  • DZ4180-080-035-0095U STEP FILE
  • DZ4180-080-035-0100U STEP FILE
  • DZ4180-080-035-0105U STEP FILE
  • DZ4180-080-035-0110U STEP FILE
  • DZ4180-080-035-0115U STEP FILE
  • DZ4180-080-035-0120U STEP FILE
  • DZ4180-080-035-0125U STEP FILE
  • DZ4180-080-035-0130U STEP FILE
  • DZ4180-080-035-0135U STEP FILE
  • DZ4180-080-035-0140U STEP FILE
  • DZ4180-080-035-0145U STEP FILE
  • DZ4180-080-035-0150U STEP FILE
  • DZ4180-080-035-0155U STEP FILE
  • DZ4180-080-035-0160U STEP FILE
  • DZ4180-080-035-0165U STEP FILE
  • DZ4180-080-035-0170U STEP FILE
  • DZ4180-080-035-0175U STEP FILE
  • DZ4180-080-035-0180U STEP FILE
  • DZ4180-080-035-0185U STEP FILE
  • DZ4180-080-035-0190U STEP FILE
  • DZ4180-080-035-0195U STEP FILE
  • DZ4180-080-035-0200U STEP FILE
