Accuride DZ5517-50 Drawer Runners and Slides Featuring Hold In and Bayonet Mounting

Only %1 left
SKU
DZ5517-50
More Information
Available Load Ratings 50Kg, 51Kg, 53Kg, 55Kg
Slide Lengths 350mm, 400mm, 450mm, 500mm, 550mm, 600mm, 700mm
Travel Range 374mm, 424mm, 473mm, 522mm, 571mm, 620mm, 731mm
Flat Mounting Cannot be Flat Mounted
Features Hold In, Bayonet Mounting
Extension 100% +
Finish Zinc Plate & Blue Passivate (DZ)
Height 53.4mm
Thickness 17.5mm
Brackets Optional Bayonet Mounting
Fixings Included No
Sold as Pairs
Model Series 5517
Catalogues
Accuride Datasheets
BASIC PRICE £45.55
All prices exclude VAT

- Accuride limited lifetime guarantee

- DZ zinc plating salt spray tested to over 12hrs

- Need it in a hurry? Accuride Quickship is available

Metrol Springs
DZ5517-50
/media/catalog/product/5/5/5517-50_2_-resized.jpg
  • Product code
    Product Description
    Stock Status
  • DZ5517-5035
    Slide Length: 350mm, Load Rating: 51Kg, Sold as: Pairs
  • DZ5517-5040
    Slide Length: 400mm, Load Rating: 53Kg, Sold as: Pairs
  • DZ5517-5045
    Slide Length: 450mm, Load Rating: 55Kg, Sold as: Pairs
  • DZ5517-5050
    Slide Length: 500mm, Load Rating: 55Kg, Sold as: Pairs
  • DZ5517-5055
    Slide Length: 550mm, Load Rating: 55Kg, Sold as: Pairs
  • DZ5517-5060
    Slide Length: 600mm, Load Rating: 53Kg, Sold as: Pairs
  • DZ5517-5070
    Slide Length: 700mm, Load Rating: 50Kg, Sold as: Pairs
  • DZLADD-0060-2
    Sold as: Kits (Front and Rear Strip)
Accuride CAD files
  • DZ5517-5035 STEP FILE
  • DZ5517-5040 STEP FILE
  • DZ5517-5045 STEP FILE
  • DZ5517-5050 STEP FILE
  • DZ5517-5055 STEP FILE
  • DZ5517-5060 STEP FILE
  • DZ5517-5070 STEP FILE
