Accuride DZ9308-E Drawer Runners and Slides with Lock In and Lock Out Features

Only %1 left
SKU
DZ9308-E4
More Information
Available Load Ratings 182Kg, 196Kg, 204Kg, 218Kg, 228Kg, 237Kg, 248Kg, 253Kg, 256Kg, 258Kg, 261Kg, 264Kg, 272Kg
Slide Lengths 254mm, 304.8mm, 355.6mm, 406.4mm, 457.2mm, 508mm, 558.8mm, 609.6mm, 660.4mm, 711.2mm, 762mm, 812.8mm, 863.6mm, 914.4mm, 1016mm, 1066.8mm, 1117.6mm, 1219.2mm, 1371.6mm, 1524mm
Travel Range 254mm, 304.8mm, 355.6mm, 406.4mm, 457.2mm, 508mm, 558.8mm, 609.6mm, 660.4mm, 711.2mm, 762mm, 812.8mm, 863.6mm, 914.4mm, 1016mm, 1066.8mm, 1117.6mm, 1219.2mm, 1371.6mm, 1524mm
Flat Mounting Cannot be Flat Mounted
Features Lock In, Lock Out
Extension 100%
Finish Zinc Plate & Blue Passivate (DZ)
Height 76.2mm
Thickness 19.1mm
Brackets Optional Screw In
Fixings Included No
Sold as Individually
Model Series 9308
Catalogues
Accuride Datasheets
main product photo
BASIC PRICE £66.72
All prices exclude VAT

- Accuride limited lifetime guarantee

- DZ zinc plating salt spray tested to over 12hrs

- Need it in a hurry? Accuride Quickship is available

Metrol Springs
DZ9308-E4
/media/catalog/product/9/3/9308-e4_2_-resized.jpg
Add to Favourites
Note: adds the product to your favourites list in your account
  • Product code
    Product Description
    Stock Status
  • DZ9308-0010L-E4
    Orientation: Left Handed, Slide Length: 254mm, Load Rating: 272Kg, Sold as: Individually
  • DZ9308-0012L-E4
    Orientation: Left Handed, Slide Length: 304.8mm, Load Rating: 272Kg, Sold as: Individually
  • DZ9308-0014L-E4
    Orientation: Left Handed, Slide Length: 355.6mm, Load Rating: 272Kg, Sold as: Individually
  • DZ9308-0016L-E4
    Orientation: Left Handed, Slide Length: 406.4mm, Load Rating: 272Kg, Sold as: Individually
  • DZ9308-0018L-E4
    Orientation: Left Handed, Slide Length: 457.2mm, Load Rating: 272Kg, Sold as: Individually
  • DZ9308-0020L-E4
    Orientation: Left Handed, Slide Length: 508mm, Load Rating: 272Kg, Sold as: Individually
  • DZ9308-0022L-E4
    Orientation: Left Handed, Slide Length: 558.8mm, Load Rating: 272Kg, Sold as: Individually
  • DZ9308-0024L-E4
    Orientation: Left Handed, Slide Length: 609.6mm, Load Rating: 267Kg, Sold as: Individually
  • DZ9308-0026L-E4
    Orientation: Left Handed, Slide Length: 660.4mm, Load Rating: 264Kg, Sold as: Individually
  • DZ9308-0028L-E4
    Orientation: Left Handed, Slide Length: 711.2mm, Load Rating: 261Kg, Sold as: Individually
  • DZ9308-0030L-E4
    Orientation: Left Handed, Slide Length: 762mm, Load Rating: 258Kg, Sold as: Individually
  • DZ9308-0032L-E4
    Orientation: Left Handed, Slide Length: 812.8mm, Load Rating: 256Kg, Sold as: Individually
  • DZ9308-0034L-E4
    Orientation: Left Handed, Slide Length: 863.6mm, Load Rating: 253Kg, Sold as: Individually
  • DZ9308-0036L-E4
    Orientation: Left Handed, Slide Length: 914.4mm, Load Rating: 248Kg, Sold as: Individually
  • DZ9308-0040L-E4
    Orientation: Left Handed, Slide Length: 1016mm, Load Rating: 237Kg, Sold as: Individually
  • DZ9308-0042L-E4
    Orientation: Left Handed, Slide Length: 1066.8mm, Load Rating: 228Kg, Sold as: Individually
  • DZ9308-0044L-E4
    Orientation: Left Handed, Slide Length: 1117.6mm, Load Rating: 218Kg, Sold as: Individually
  • DZ9308-0048L-E4
    Orientation: Left Handed, Slide Length: 1219.2mm, Load Rating: 204Kg, Sold as: Individually
  • DZ9308-0054L-E4
    Orientation: Left Handed, Slide Length: 1371.6mm, Load Rating: 196Kg, Sold as: Individually
  • DZ9308-0060L-E4
    Orientation: Left Handed, Slide Length: 1524mm, Load Rating: 182Kg, Sold as: Individually
  • DZ9308-0010R-E4
    Orientation: Right Handed, Slide Length: 254mm, Load Rating: 272Kg, Sold as: Individually
  • DZ9308-0012R-E4
    Orientation: Right Handed, Slide Length: 304.8mm, Load Rating: 272Kg, Sold as: Individually
  • DZ9308-0014R-E4
    Orientation: Right Handed, Slide Length: 355.6mm, Load Rating: 272Kg, Sold as: Individually
  • DZ9308-0016R-E4
    Orientation: Right Handed, Slide Length: 406.4mm, Load Rating: 272Kg, Sold as: Individually
  • DZ9308-0018R-E4
    Orientation: Right Handed, Slide Length: 457.2mm, Load Rating: 272Kg, Sold as: Individually
  • DZ9308-0020R-E4
    Orientation: Right Handed, Slide Length: 508mm, Load Rating: 272Kg, Sold as: Individually
  • DZ9308-0022R-E4
    Orientation: Right Handed, Slide Length: 558.8mm, Load Rating: 272Kg, Sold as: Individually
  • DZ9308-0024R-E4
    Orientation: Right Handed, Slide Length: 609.6mm, Load Rating: 267Kg, Sold as: Individually
  • DZ9308-0026R-E4
    Orientation: Right Handed, Slide Length: 660.4mm, Load Rating: 264Kg, Sold as: Individually
  • DZ9308-0028R-E4
    Orientation: Right Handed, Slide Length: 711.2mm, Load Rating: 261Kg, Sold as: Individually
  • DZ9308-0030R-E4
    Orientation: Right Handed, Slide Length: 762mm, Load Rating: 258Kg, Sold as: Individually
  • DZ9308-0032R-E4
    Orientation: Right Handed, Slide Length: 812.8mm, Load Rating: 256Kg, Sold as: Individually
  • DZ9308-0034R-E4
    Orientation: Right Handed, Slide Length: 863.6mm, Load Rating: 253Kg, Sold as: Individually
  • DZ9308-0036R-E4
    Orientation: Right Handed, Slide Length: 914.4mm, Load Rating: 248Kg, Sold as: Individually
  • DZ9308-0040R-E4
    Orientation: Right Handed, Slide Length: 1016mm, Load Rating: 237Kg, Sold as: Individually
  • DZ9308-0042R-E4
    Orientation: Right Handed, Slide Length: 1066.8mm, Load Rating: 228Kg, Sold as: Individually
  • DZ9308-0044R-E4
    Orientation: Right Handed, Slide Length: 1117.6mm, Load Rating: 218Kg, Sold as: Individually
  • DZ9308-0048R-E4
    Orientation: Right Handed, Slide Length: 1219.2mm, Load Rating: 204Kg, Sold as: Individually
  • DZ9308-0054R-E4
    Orientation: Right Handed, Slide Length: 1371.6mm, Load Rating: 196Kg, Sold as: Individually
  • DZ9308-0060R-E4
    Orientation: Right Handed, Slide Length: 1524mm, Load Rating: 182Kg, Sold as: Individually
  • DZ63412
    Sold as: Pairs
  • DZ63416
    Sold as: Pairs
  • DZ63422
    Sold as: Pairs
  • DZ63428
    Sold as: Pairs
CAD Files
Accuride CAD files
  • DZ9308-0010L STEP FILE
  • DZ9308-0012L STEP FILE
  • DZ9308-0014L STEP FILE
  • DZ9308-0016L STEP FILE
  • DZ9308-0018L STEP FILE
  • DZ9308-0020L STEP FILE
  • DZ9308-0022L STEP FILE
  • DZ9308-0024L STEP FILE
  • DZ9308-0026L STEP FILE
  • DZ9308-0028L STEP FILE
  • DZ9308-0030L STEP FILE
  • DZ9308-0032L STEP FILE
  • DZ9308-0034L STEP FILE
  • DZ9308-0036L STEP FILE
  • DZ9308-0040L STEP FILE
  • DZ9308-0042L STEP FILE
  • DZ9308-0044L STEP FILE
  • DZ9308-0048L STEP FILE
  • DZ9308-0054L STEP FILE
  • DZ9308-0060L STEP FILE
  • DZ9308-0010R STEP FILE
  • DZ9308-0012R STEP FILE
  • DZ9308-0014R STEP FILE
  • DZ9308-0016R STEP FILE
  • DZ9308-0018R STEP FILE
  • DZ9308-0020R STEP FILE
  • DZ9308-0022R STEP FILE
  • DZ9308-0024R STEP FILE
  • DZ9308-0026R STEP FILE
  • DZ9308-0028R STEP FILE
  • DZ9308-0030R STEP FILE
  • DZ9308-0032R STEP FILE
  • DZ9308-0034R STEP FILE
  • DZ9308-0036R STEP FILE
  • DZ9308-0040R STEP FILE
  • DZ9308-0042R STEP FILE
  • DZ9308-0044R STEP FILE
  • DZ9308-0048R STEP FILE
  • DZ9308-0054R STEP FILE
  • DZ9308-0060R STEP FILE
