DB1234 pocket door package for partial overlay doors up to 1100mm high, from 510mm depth

SKU
DB1234-0050-1100-2
More Information
Cabinet Depth From 510mm
Cabinet Depth 500mm+
Available Load Ratings 14Kg
Max. Door Height 700mm, 900mm, 1065mm, 1100mm
Door Width 610mm
Door Fitting Partial Overlay
Door Thickness 21-32mm
Mounting Options Vertical, Horizontal
Model Series DB1234
Package Suitability Suitable for one door
Package Contents 1 pair slides, 1 pair hinges
Accuride Datasheets
Catalogues
£67.20
All prices exclude VAT
VOLUME DISCOUNTS
  • QUANTITYPRICE
  • 5 + £58.86
Metrol Springs
DB1234-0050-1100-2
/media/catalog/product/d/b/db1234-package_3.jpg
  • Product code
    Product Description
    Stock Status
  • DB1234-0050-1100-2
    DB1234 pocket door package for partial overlay doors up to 1100mm high, from 510mm depth
Accuride CAD files
  • DB1234-0050 STEP FILE
