DB1432 pocket door package for inset doors up to 1400mm high, from 428mm depth

SKU
DB1432-0040-1400-1
More Information
Cabinet Depth From 428mm
Cabinet Depth 400mm+
Available Load Ratings 34Kg
Max. Door Height 700mm, 900mm, 1065mm, 1100mm, 1200mm, 1400mm
Door Width 255-660mm
Door Fitting Inset
Door Thickness 19-20.6mm
Mounting Options Vertical
Model Series DB1432
Package Suitability Suitable for one door
Package Contents 1 pair slides, 2 pairs hinges, 2 hinge carrier strips
Slide Lengths 405mm
Accuride Datasheets
Catalogues
£153.44
All prices exclude VAT
VOLUME DISCOUNTS
  • QUANTITYPRICE
  • 5 + £134.26
Metrol Springs
DB1432-0040-1400-1
/media/catalog/product/d/b/db1432-package1_9.jpg
  • Product code
    Product Description
    Stock Status
  • DB1432-0040-1400-1
    DB1432 pocket door package for inset doors up to 1400mm high, from 428mm depth
Accuride CAD files
  • DB1432-0040 STEP FILE
