Accuride DZ2002 Two Way Travel Drawer Runners and Slides with Hold In Feature

Only %1 left
SKU
DZ2002
More Information
Available Load Ratings 24Kg, 27Kg, 29Kg, 31Kg, 32Kg, 35Kg
Slide Lengths 305mm, 356mm, 406mm, 457mm, 508mm, 558mm, 610mm, 660mm, 711mm
Travel Range 221.5mm, 272.3mm, 297.7mm, 323.1mm, 373.9mm, 399.3mm, 424.7mm, 475.5mm, 500.9mm
Features Hold In
Extension 75%, Two Way Travel
Finish Zinc Plate & Blue Passivate (DZ)
Height 35.3mm
Thickness 9.5mm
Brackets Included
Fixings Included Yes
Sold as Pairs
Catalogues
Accuride Datasheets
BASIC PRICE £21.51
All prices exclude VAT

Accuride DZ2002 Two Way Travel Drawer Runners and Slides with Hold In Feature - Slide Lengths options are 305mm, 356mm, 406mm, 457mm, 508mm, 558mm, 610mm, 660mm, 711mm, Available Load Ratings options are 24Kg, 27Kg, 29Kg, 31Kg, 32Kg, 35Kg, Features options are Hold In, Two Way Travel, Travel Range options are 221.5mm, 272.3mm, 297.7mm, 323.1mm, 373.9mm, 399.3mm, 424.7mm, 475.5mm, 500.9mm, Extension options are 75%, Finish options are Zinc Plate & Blue Passivate (DZ), Height options are 35.3mm, Thickness options are 9.5mm, Brackets options are Included, Fixings Included options are Male, Sold in pairs

Metrol Springs
DZ2002
/media/catalog/product/2/0/2002_2_-resized.jpg
  • Product code
    Product Description
    Stock Status
  • DZ2002-0012-2
    Slide Length: 305mm, Load Rating: 35Kg, Sold as: Pairs
  • DZ2002-0014-2
    Slide Length: 356mm, Load Rating: 35Kg, Sold as: Pairs
  • DZ2002-0016-2
    Slide Length: 406mm, Load Rating: 35Kg, Sold as: Pairs
  • DZ2002-0018-2
    Slide Length: 457mm, Load Rating: 35Kg, Sold as: Pairs
  • DZ2002-0020-2
    Slide Length: 508mm, Load Rating: 32Kg, Sold as: Pairs
  • DZ2002-0022-2
    Slide Length: 558mm, Load Rating: 31Kg, Sold as: Pairs
  • DZ2002-0024-2
    Slide Length: 610mm, Load Rating: 29Kg, Sold as: Pairs
  • DZ2002-0026-2
    Slide Length: 660mm, Load Rating: 27Kg, Sold as: Pairs
  • DZ2002-0028-2
    Slide Length: 711mm, Load Rating: 24Kg, Sold as: Pairs
  • DZ2002
    Sold as: Pairs
Accuride CAD files
  • DZ2002-0012 STEP FILE
  • DZ2002-0014 STEP FILE
  • DZ2002-0016 STEP FILE
  • DZ2002-0018 STEP FILE
  • DZ2002-0020 STEP FILE
  • DZ2002-0022 STEP FILE
  • DZ2002-0024 STEP FILE
  • DZ2002-0026 STEP FILE
  • DZ2002-0028 STEP FILE
