Accuride DZ3507 Drawer Runners and Slides with Lock Out and Disconnect Features

Only %1 left
SKU
DZ3507
More Information
Available Load Ratings 67Kg, 71Kg, 73Kg, 76Kg, 78Kg, 80Kg, 81Kg, 82Kg
Slide Lengths 406mm, 457mm, 508mm, 559mm, 610mm, 660mm, 711mm, 762mm
Travel Range 457mm, 508mm, 559mm, 610mm, 660mm, 711mm, 762mm, 813mm
Features Disconnect, Lock Out
Extension 100% +
Finish Zinc Plate & Blue Passivate (DZ)
Height 51.6mm
Thickness 12.7mm
Brackets Optional Screw In
Fixings Included No
Sold as Pairs
Catalogues
Accuride Datasheets
main product photo
BASIC PRICE £70.76
All prices exclude VAT

Accuride DZ3507 Drawer Runners and Slides with Lock Out and Disconnect Features - Features options are Disconnect, Lock Out, Travel Range options are 457mm, 508mm, 559mm, 610mm, 660mm, 711mm, 762mm, 813mm, Slide Lengths options are 406mm, 457mm, 508mm, 559mm, 610mm, 660mm, 711mm, 762mm, Available Load Ratings options are 67Kg, 71Kg, 73Kg, 76Kg, 78Kg, 80Kg, 81Kg, 82Kg, Extension options are 100% +, Finish options are Zinc Plate & Blue Passivate (DZ), Height options are 51.6mm, Thickness options are 12.7mm, Brackets options are Optional, Sold in pairs

Metrol Springs
DZ3507
/media/catalog/product/3/5/3507_2_-resized.jpg
Add to Favourites
Note: adds the product to your favourites list in your account
  • Product code
    Product Description
    Stock Status
  • DZ3507-0016
    Slide Length: 406mm, Load Rating: 71Kg, Sold as: Pairs
  • DZ3507-0018
    Slide Length: 457mm, Load Rating: 76Kg, Sold as: Pairs
  • DZ3507-0020
    Slide Length: 508mm, Load Rating: 80Kg, Sold as: Pairs
  • DZ3507-0022
    Slide Length: 559mm, Load Rating: 82Kg, Sold as: Pairs
  • DZ3507-0024
    Slide Length: 610mm, Load Rating: 81Kg, Sold as: Pairs
  • DZ3507-0026
    Slide Length: 660mm, Load Rating: 78Kg, Sold as: Pairs
  • DZ3507-0028
    Slide Length: 711mm, Load Rating: 73Kg, Sold as: Pairs
  • DZ3507-0030
    Slide Length: 762mm, Load Rating: 67Kg, Sold as: Pairs
  • DZ3507
    Sold as: Pairs
  • DZ63485-4
    Sold as: Kits
CAD Files
Accuride CAD files
  • DZ3507-0016 STEP FILE
  • DZ3507-0018 STEP FILE
  • DZ3507-0020 STEP FILE
  • DZ3507-0022 STEP FILE
  • DZ3507-0024 STEP FILE
  • DZ3507-0026 STEP FILE
  • DZ3507-0028 STEP FILE
  • DZ3507-0030 STEP FILE
