Accuride DZ5321EC Drawer Runners and Slides with Soft Close Feature

Only %1 left
SKU
DZ5321EC
More Information
Available Load Ratings 65Kg, 70Kg, 75Kg, 80Kg, 85Kg, 90Kg, 100Kg
Slide Lengths 400mm, 450mm, 500mm, 550mm, 600mm, 700mm, 800mm, 900mm, 1000mm, 1100mm
Travel Range 388mm, 450mm, 500mm, 550mm, 600mm, 700mm, 800mm, 900mm, 1000mm, 1100mm
Features Soft Close (EC)
Extension 100%
Finish Zinc Plate & Blue Passivate (DZ)
Height 53.1mm
Thickness 19.1mm
Brackets Optional Screw In
Fixings Included No
Sold as Pairs
Accuride Datasheets
Catalogues
BASIC PRICE £67.29
All prices exclude VAT

Accuride DZ5321EC Drawer Runners and Slides with Soft Close Feature - Features options are Soft Close (EC), Travel Range options are 388mm, 450mm, 500mm, 550mm, 600mm, 700mm, 800mm, 900mm, 1000mm, 1100mm, Slide Lengths options are 400mm, 450mm, 500mm, 550mm, 600mm, 700mm, 800mm, 900mm, 1000mm, 1100mm, Available Load Ratings options are 65Kg, 70Kg, 75Kg, 80Kg, 85Kg, 90Kg, 100Kg, Extension options are 100%, Finish options are Zinc Plate & Blue Passivate (DZ), Height options are 53.1mm, Thickness options are 19.1mm, Brackets options are Optional, Sold in pairs

Metrol Springs
DZ5321EC
/media/catalog/product/5/3/5321ec_2_-resized.jpg
  • Product code
    Product Description
    Stock Status
  • DZ5321-0040EC
    Slide Length: 400mm, Load Rating: 65Kg, Sold as: Pairs
  • DZ5321-0045EC-A
    Slide Length: 450mm, Load Rating: 65Kg, Sold as: Pairs
  • DZ5321-0050EC
    Slide Length: 500mm, Load Rating: 70Kg, Sold as: Pairs
  • DZ5321-0055EC
    Slide Length: 550mm, Load Rating: 85Kg, Sold as: Pairs
  • DZ5321-0060EC
    Slide Length: 600mm, Load Rating: 100Kg, Sold as: Pairs
  • DZ5321-0070EC-A
    Slide Length: 700mm, Load Rating: 100Kg, Sold as: Pairs
  • DZ5321-0080EC-A
    Slide Length: 800mm, Load Rating: 90Kg, Sold as: Pairs
  • DZ5321-0090EC-A
    Slide Length: 900mm, Load Rating: 85Kg, Sold as: Pairs
  • DZ5321-0100EC-A
    Slide Length: 1000mm, Load Rating: 80Kg, Sold as: Pairs
  • DZ5321-0110EC-A
    Slide Length: 1100mm, Load Rating: 75Kg, Sold as: Pairs
  • DZ5321EC
    Sold as: Pairs
  • DZ63530
    Sold as: Pairs
  • DZ63540
    Sold as: Pairs
  • DZ63550
    Sold as: Pairs
  • DZ63560
    Sold as: Pairs
Accuride CAD files
  • DZ5321-0040EC STEP FILE
  • DZ5321-0045EC STEP FILE
  • DZ5321-0050EC STEP FILE
  • DZ5321-0055EC STEP FILE
  • DZ5321-0060EC STEP FILE
  • DZ5321-0070EC STEP FILE
  • DZ5321-0080EC STEP FILE
  • DZ5321-0090EC STEP FILE
  • DZ5321-0100EC STEP FILE
  • DZ5321-0110EC STEP FILE
